690VAC 400A Bolt Connected High-Speed Fuse
  • 690VAC 400A Bolt Connected High-Speed Fuse690VAC 400A Bolt Connected High-Speed Fuse
  • 690VAC 400A Bolt Connected High-Speed Fuse690VAC 400A Bolt Connected High-Speed Fuse

690VAC 400A Bolt Connected High-Speed Fuse

Galaxy Fuse (Yinrong), a reputable high speed fuse manufacturer based in China, offers a specialized product called the 690VAC 400A Bolt Connected High-Speed Fuse, which is designed to provide short-circuit protection for semiconductor devices. With an amperage rating ranging from 160A to 400A under a rated voltage of 690VAC/550VDC, the 690VAC 400A Bolt Connected High-Speed Fuse is suitable for a wide range of semiconductor devices. the 690VAC 400A Bolt Connected High-Speed Fuse conforms to the GB13539.4 and IEC60269-4 standards, ensuring excellent quality and reliability. Moreover, with its strong R&D capabilities, Galaxy Fuse (Yinrong) offers a variety of high speed fuses to cater to the evolving energy storage industry.

Send Inquiry

Product Description

Galaxy Fuse (Yinrong), a reliable high speed fuse manufacturer based in China, manufactures and supplies the 690VAC 400A Bolt Connected High-Speed Fuse, which is designed to protect semiconductor devices.This fuse is specifically engineered for short-circuit protection and has an amperage rating of 160A to 400A under a rated voltage of 690VAC/550VDC, which makes it suitable for most semiconductor devices. The 690VAC 400A Bolt Connected High-Speed Fuse conforms to both GB13539.4 and IEC60269-4 standards, which ensures its high quality and reliability. In addition to this product, Galaxy Fuse (Yinrong) also offers a broad range of high speed fuses to meet the growing needs of the emerging energy storage industry.

Standard/Compliance

-IEC 60269-4

-GB/T13539.4

Class of Operation

aR

Features&Benefits

- 690VAC /550VDC electrical system available

- 160-400A ampere ratings available

- High breaking capacity

- BS88 style bolted tag mounting

- Offers max 400 amperage in compact size

- Conforms to IEC standards for global acceptance

- Low power loss and temperature rise for energy efficiency

Applications of 690VAC 400A  Bolt Connected High-Speed Fuse

- Power converters/rectifiers

- AC/DC common systems

- Frequency converters

- Battery energy storage systems

- Regenerative drives

- Other semiconductors

Country of Origin

People’s Republic of China

Parameters

P/N

Current(A)

I²t (A²s) 690VAC/550VDC

Power Loss

(W)

Mounting

Pre-arcing

Melt

YRGS7-690V/160A

160A

1322

11020

39

Bolt M10

Torque

15N.m

YRGS7-690V/180A

180A

1979

17950

43

YRGS7-690V/200A

200A

3325

23840

48

YRGS7-690V/250A

250A

4107

31870

55

YRGS7-690V/280A

280A

6987

52130

62

YRGS7-690V/315A

315A

9732

72530

70

YRGS7-690V/350A

350A

12060

92580

75

YRGS7-690V/400A

400A

30890

198600

80

Sizes

Time-Current Characteristic

Cut-off Current Characteristic
